TFC Series Industry Flake Ice Maker
  • Name: TFC Series Industry Flake Ice Maker
  • Model : TFC Series
  • Erp code: 1000000097
    • | Share


Specification:

Standard Working Condition: Ambient Temp: 25℃, Water Inlet Temp: 16℃
Applicable Condition: Ambient Temp: 5℃-40℃, Water Inlet Temp: 0℃-40℃
Flake Ice Thickness: 1.5-2.2mm
Refrigerant: R22/R404A


No. Specifications Value
01 Ice production capacity 20t/24h
02 Cooling power 127.6KW
03 Evaporation temperature-20°C
04 Condensing temperature 38°C
05 Total installed power 77 KW
06 Compressor input power 68.9 KW
07 Reducer Power 0.75 KW
08 Ice bucket pump input power 0.75 KW
09 condensate pump input power 5.5 KW
10 Cooling tower fan input power 1.1 KW
11 Power supply 3P/380V/50Hz
12 Water pressure 0.1Mp－0.5Mpa
13 Refrigerant R404a
14 Flake ice temperature-5℃
15 Flake ice thickness 1.5mm-2.2mm
16 Ambient temperature 25℃
17 Water temperature 20℃
18 Net weight 1.4
19 Water consumption 2*3/4"
20 Pipe over size 3820KG
21 Dimensions 4000*2100*2200
Excluding ice storage size




Parameters:


No. Specifications Value
01 Ice production capacity 20t/24h
02 Cooling power 127.6KW
03 Evaporation temperature-20°C
04 Condensing temperature 38°C
05 Total installed power 77 KW
06 Compressor input power 68.9 KW
07 Reducer Power 0.75 KW
08 Ice bucket pump input power 0.75 KW
09 condensate pump input power 5.5 KW
10 Cooling tower fan input power 1.1 KW
11 Power supply 3P/380V/50Hz
12 Water pressure 0.1Mp－0.5Mpa
13 Refrigerant R404a
14 Flake ice temperature-5℃
15 Flake ice thickness 1.5mm-2.2mm
16 Ambient temperature 25℃
17 Water temperature 20℃
18 Net weight 1.4
19 Water consumption 2*3/4"
20 Pipe over size 3820KG
21 Dimensions 4000*2100*2200
Excluding ice storage size
