Application area：
Suitable for measuring ash Fusion in coal ash for industries such as electric power, coal, commodity inspection, environmental protection , metallurgy , papermaking , chemical industry, collate industry, science & research institution and inspection administration.
Technical Data:
Furnace Temperature Range: 0°C~1600°C
Temperature Controlling Accuracy: < 3°C
Resolution: 1°C
Sample Quantity: 1~7 samples each time
Laboratory Atmosphere: Oxidability or weak reducibility
Power Supply: 220V, 50/60HZ
Maximum Power: ≤ 4KW
Cabinet Dimension: 910mm×520mm×610 mm
Weight: 75kgs
Features Highlight:
Using imported materials, special double-layer hearth, insulation layer, 1800 DEG C temperature Gaokenai, the outer layers of the insulation is good, at the bottom of the surface temperature, high strength, thus the furnace both have good heat preservation performance, energy saving and effectively prevent the hearth by external force impact deformation or damage.
Using advanced CCD imaging technology, real-time monitoring of the whole process, automatic judgment of the four characteristics of the molten temperature of the sample.
3. The unique seal can be used to ensure the test atmosphere: oxidizing atmosphere, weak reducing atmosphere and strong reducing atmosphere.
4. Silicon molybdenum rod is heated, the furnace temperature can reach 1600 degrees Celsius, the sample range is wider and the result is more accurate.
Technical Data:
Furnace Temperature Range: 0°C~1600°C
Temperature Controlling Accuracy: < 3°C
Resolution: 1°C
Sample Quantity: 1~7 samples each time
Laboratory Atmosphere: Oxidability or weak reducibility
Power Supply: 220V, 50/60HZ
Maximum Power: ≤ 4KW
Cabinet Dimension: 910mm×520mm×610 mm
Weight: 75kgs
