Specification:

1. Usage: automatic cleaning of screen frame;

2. Function characteristics: opening-cover detection function to better protect the operator not splashed by liquid; low liquid alarm function, preventing dry heating function, automatic constant temperature function, automatic regular alarm function;

3. Screen cleaning pressure: 2-4 KG/cm2 adjustable;

4. Screen cleaning mode: hanging double sided spraying cleaning;

5. ★Control system: high-performance ARM embedded processor + embedded operating system, human-computer interface: big screen color LCD screen + touch screen; In touch screen you can read electronic edition screen cleaning process manual; In touch screen you can play the circuit board design sketch after screen cleaning process;

6. Screen cleaning time: 30-50s/net,0~99min59s software can be set;

7. Screen cleaning dimension: 480×420mm;

8. Liquid volume: 35L;

9. ★Optional configuration: Ethernet interface, realizing remote diagnosis, monitoring, booking open and close the machine and etc. through the wireless or local area network and the Internet, seamless connection with network management system and software, mating PCB network management software, providing long-term free upgrades service;

10. Power supply: AC220V/50Hz,rated power: 2.5KW;

11. Overall dimension: length 935mm×width 660mm×height 760 mm;

12. Net weight: 80KG.
