Specification:

1. Usage: drying and curing of line, resistant welding and character ink and the drying of silk-screen frame;

2. Structure characteristics: automatic cycle wind heating, making the temperature more uniform; with heat insulation shell, temperature rises more quickly; container with mirror surface of stainless steel, beautiful and durable;

3. Function characteristics: automatic shutdown at fixed time, automatic alarm and automatic constant temperature;

4. Temperature adjustment range: room temperature~260°C adjustable;

5. Time setting: 0~999 min adjustable;

6. Drying room volume: length 500mm×width 600mm×height 750mm;

7. ★With three stainless steel layers dividing drying room into four layers; equipped with stainless steel special board frame, with 7 fixed PCB slots, baking 7 pieces of PCB at the same time;

8. Heating power: 2400W;

9. Power supply: AC220V/50Hz;

10. Entire machine power: 2500W;

11. Overall dimension: length 900mm×width 830mm×height 1100mm;

12. Weight: 80Kg.
