Specification:

1. Usage: drying and curing of line, resistant welding and character ink;

2. Structure characteristics: automatic cycle wind heating, making the temperature more uniform; container with mirror surface of stainless steel, beautiful and durable; with heat insulation shell, temperature rises more quickly;

3. Function characteristics: automatic shutdown at fixed time, automatic alarm and automatic constant temperature;

4. Temperature adjustment range: room temperature~250°C adjustable;

5. Temperature resolution: 1°C;

6. Temperature fluctuation degree: ±1°C;

7. Time setting: 0~999 min adjustable;

8. Drying room volume: length 350mm×width 350mm×height 350mm;

9. Heating power: 500W;

10. ★With two stainless steel layers dividing drying room into three layers; equipped with stainless steel special board frame, with seven fixed PCB slots, baking 7 pieces of PCB at the same time;

11. Power supply: AC220V/50Hz;

12. Entire machine power: 550W;

13. Overall dimension: length 640mm×width 485mm×height 545mm;

14. Weight: 50Kg.
