Optical system
l full spectrum optical system of Palmer type - runge structure
l Maximum wavelength range: 130 ~ 800 nm
l Multiple high performance CCD detector
l Integrated optical chamber process molding, resistant to change of environment temperature
l Vacuum light chamber design guarantees C, S, P, could achieve the best performance.
l light room temperature control, constant temperature is 35 °C
l Directed type optical technology and lens MgF2 materials ensure that the best energy of UV wavelength of C, S, P.
Specification and technical parameter:
Item | Indicator |
Detection substrate | Fe |
Detection time | According to the type of test sample, usually it is about 25s. |
Optical system | Palmer type - runge Rowland circle full spectrum vacuum type optical system |
Wavelength range | 130 ~ 800nm |
Focal length | 400mm |
Detector | high-performance CCD array |
Electrode | Tungsten material spray electrode |
Analytical gap | Sample Stage Analytical gap:3.4mm |
Operating temperature | (10 ~ 35)°C |
Storage temperature | (0 ~ 45)°C |
Operating humidity | 20％ ~ 80％ |
Argon purity requirements | 99.999% |
Argon gas inlet pressure | 0.5MPa |
Argon flow | Stimulating flow is about 3.5L/min, maintaining flow is about 0.4L/min. |
Stimulating max power | 400VA |
Light source type | brand new adjustable digital light source, high energy preliminary combustion science (HEPS) |
Discharge frequency | 100-1000 Hz |
Discharge current | Max 400A |
Spark Stand aperture | 13mm |
Vacuum system | Vacuum software automatically control and monitor |
Working power | 220V AC, 50/60Hz, the single-phase power supply of protective grounding |
Instrument dimensions | 860*720*500 |
Instrument weight | 80kg |
Specification and technical parameter
Item | Indicator |
Detection substrate | Fe |
Detection time | According to the type of test sample, usually it is about 25s. |
Optical system | Palmer type - runge Rowland circle full spectrum vacuum type optical system |
Wavelength range | 130 ~ 800nm |
Focal length | 400mm |
Detector | high-performance CCD array |
Electrode | Tungsten material spray electrode |
Analytical gap | Sample Stage Analytical gap:3.4mm |
Operating temperature | (10 ~ 35)°C |
Storage temperature | (0 ~ 45)°C |
Operating humidity | 20％ ~ 80％ |
Argon purity requirements | 99.999% |
Argon gas inlet pressure | 0.5MPa |
Argon flow | Stimulating flow is about 3.5L/min, maintaining flow is about 0.4L/min. |
Stimulating max power | 400VA |
Light source type | brand new adjustable digital light source, high energy preliminary combustion science (HEPS) |
Discharge frequency | 100-1000 Hz |
Discharge current | Max 400A |
Spark Stand aperture | 13mm |
Vacuum system | Vacuum software automatically control and monitor |
Working power | 220V AC, 50/60Hz, the single-phase power supply of protective grounding |
Instrument dimensions | 860*720*500 |
Instrument weight | 80kg |
